The AT72D is a multimounting, stepdown transformaer for use in 24 Vac control systems. It is listed by Underwriters Laboratories Inc. and Canadian Standards Associations, and meets NEC Class 2 not wet Class 3 wet requirements. It also complies with 24 V NEMA Type D requirements as specified by NEMA Standard ST2-1979.
AT72D mounting options include foot mounting. plate mounting; plate mounting (transformer all above plate, or 3/4 above plate) for use in 4 x 4 in., 4 in octagon, and 2 x 4 in. electrical boxes; and clam mounting via a junction box knockout.
|Application||24 V Controls|
|Voltage (Secondary)||26.5 V.O.C.|
|Wiring|| 9" Leadwires
2 Screw Terminals
|Electrical Output||24 Vac at 40 VA|
|NEMA rating||Type D|
